Rama:
Alpha Platinum Aluminium, tapered head tube, internal routing, BSA 73, hidden rack and kickstand mounts, UDH, Boost148, 12 mm thru axle
Prednja vilica:
RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15 mm Maxle Stealth, 120mm travel
Prednja glavčina:
Shimano TC500 alloy, CentreLock, 110×15 mm thru axle
Zadnja glavčina:
Shimano TC500 alloy, CentreLock, 148×12 mm thru axle
Obruči:
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Gume:
Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29×2.40”
Ručice mjenjača:
Shimano SLX M7100, 12-speed
Zadnji mjenjač:
Shimano XT M8100, long cage
Pogon:
E*thirteen Helix, 30T steel ring, 73 mm spindle length, 52 mm chainline
Osovina pogona:
Shimano BB-MT501 BSA
Kazeta:
Shimano SLX M7100, 10-51T, 12-speed
Lanac:
Shimano SLX M7100, 12-speed
Pedale:
VP-536 nylon platform
Sjedalo:
Verse Short, chromoly rails, 145 mm width
Cijev sjedala:
Bontrager Line Dropper, MaxFlow, internal routing, 31.6 mm
Kormilo:
Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width (Size: S , M: 5 mm rise, 720 mm width)
Navlake kormila:
Bontrager XR Trail Comp, nylon lock-on
Lula kormila:
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree
Garnitura vilice:
Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8” top, 1.5” bottom
Kočnice:
Shimano hydraulic disc, MT4100 lever, MT410 calliper
Težina:
M – 12.78 kg / 28.18 lbs (with TLR sealant, no tubes)
Godina modela:
2026
